11｜08｜2023

The Difference Between Indoor LED Display And Outdoor LED Display

You may know that LED displays are installed and controlled in different ways, but the most critical difference is indoor and outdoor. This is the first and most important step in choosing an LED display, and it will determine how you choose an LED display in the future. So how to distinguish between indoor and outdoor LED display? How should we choose? 1. What is an indoor LED display? Indoor LED display refers to the LED display used indoors. For example, large-scale led display screens in shopping malls, large-scale broadcast led screens in stadiums, etc. These devices are everywhere. The size and shape of the indoor LED display is customized according to the buyer's idea. Due to the small pixel pitch of the indoor LED display, the quality and clarity of the LED display are relatively high. 2. What is an outdoor LED display? Outdoor LED display refers to the LED display used outdoors. Due to direct sunlight or long-term exposure to sunlight, the brightness of the outdoor LED display will be higher. In addition, since outdoor LED advertising displays are usually used in large areas, their area is generally much larger than indoor led displays. In addition, there are semi-outdoor LED displays for outdoor LED displays, which are generally installed at the door for information release and used in advertising media in retail stores. The pixel pitch is between indoor and outdoor LED display. It is often used in front of banks, shopping malls or hospitals. Due to the high brightness, the semi-outdoor LED display can be used outdoors without direct sunlight. Due to the good sealing performance, the LED display screen body is generally installed under the eaves or under the windows. 3. How to distinguish the outdoor led screen from the indoor led screen? For users who don't know much about LED displays, there is no other way to distinguish between indoor LED displays and outdoor LED displays except to look at the installation position of the LED display. I have summarized some differences between indoor and outdoor LED displays, which can help you better distinguish. 1) waterproof Because the indoor LED display is installed indoors, there is no waterproof measure. The surface of the outdoor LED display must be impervious to water. There are many outdoor LED displays installed in places that cannot be sheltered by wind and rain. Therefore, outdoor waterproofing is essential. 2) brightness Indoor LED display brightness is low, generally 800-1200cd/m2. Since there is no direct sunlight in the room, the brightness requirement is not very high. Outdoor LED display brightness is relatively high, generally around 5000-6000cd/m2. Since the outdoor is exposed to direct sunlight for a long time, it must have a high brightness to see a clear LED display in the sun. Reminder: The indoor LED display cannot be used outdoor, because the brightness is too low to see anything. Similarly, outdoor LED displays cannot be used indoor. Because the brightness is too high, it will hurt the eyes. 3) Pixel pitch The viewing distance of indoor LED display is relatively short, so there are corresponding requirements for the picture quality and clarity of the LED display. The pixel pitch of the indoor LED display is small. The smaller the dot pitch, the better the picture quality and clarity of the LED display. The viewing distance of the outdoor LED display is relatively far, so the picture quality and clarity of the LED display are not so high. The pixel pitch of outdoor LED display is generally larger. 4) Appearance Indoor LED displays are commonly used in places of worship, restaurants, shopping malls, workplaces, meeting spaces, and retail stores. Therefore, the usable indoor led screen cabinet will be smaller. Outdoor LED displays are usually used in large places such as football fields or highway signs, so the outdoor LED display cabinet is larger than the indoor cabinet. 5) Adaptability to external weather conditions In terms of adaptation to weather conditions, indoor LED displays are different from outdoor LED displays. The indoor LED display is installed indoors and is not affected by the weather. Therefore, in addition to the IP20 waterproof rating, there is no need to take any protective measures due to changes in external weather conditions, so there is no such function. The outdoor LED display is designed to fully adapt to various weather conditions. Outdoor LED screens are generally equipped with protective measures such as leakage prevention, dustproof, sunscreen, lightning protection, and waterproof. 4. Do you need outdoor LED screen or indoor LED screen? "Do you want indoor or outdoor" is a question that LED display manufacturers will definitely ask you, so before answering, you need to know what conditions the LED display you want must meet. Are you exposed to direct sunlight? Do you need a high-definition LED display? Is the installation location indoors or outdoors? Once these are considered, you can decide whether you need an indoor or outdoor display.

24｜11｜2023

Meiyad Tell You How To Install Outdoor LED Display

When you want to buy an outdoor LED display, it is very important to quickly understand the installation process and precautions, which can reduce 83% maintenance troubles for your LED display screen, thus prolonging the service life of the outdoor billboard display. Let's quickly understand: 1) Four Steps for the installation of led displays for outdoor billboardsThe first step: Fixing of outdoor LED display When determining the high-level installation position, building a complete “cuboid” solid steel structure and adding a bracket on the back of the display screen is necessary. In this installation step, the entire outdoor LED display can be firmly supported for a long time. Step 2: Install the cabinet of the outdoor LED display The LED display screen is a large screen made up of individual cabinets. As long as any LED box is connected to the power supply, it becomes a small LED display that can display content and text. In this step, you only need to install these “small rectangular blocks” in the calculated steel structure space. Step 3: Power on and debug the outdoor LED display After the LED cabinet of the outdoor LED display is installed, it needs to be connected to the power supply, and then debug and test whether each screen is lit up, whether the screen display is clear and the color is correct, etc. In this step, in addition to debugging, you also need to check whether the lamp beads are damaged in different monochromatic displays. Step 4: Decoration of Outdoor LED Display The decoration of outdoor LED display screens is generally determined according to the building and the surrounding environment. For example, the decoration in the outdoor children’s playground will be more cute and exciting. If it is in the shopping mall, the high-end fashion decoration will give extra points to the advertisement. In this step, it is still visually beautiful, making the LED display screen integrated with the external building, making it more attractive. 2) 5 Useful Outdoor LED Screen Installation Tips1. Installation of lightning protection devices on display screens and buildings Do you know why you need to install lightning protection devices? The LED display is easily “attacked” by ultra-high voltage electricity, which instantly burns out the internal electronic equipment. Yes, if there is no lightning protection device, when there is a thunderstorm, most of the lightning power is 1-1 billion joules. In other words, just ordinary lightning is about 280 kWh, far beyond various countries’ voltage. Standard, even the highest voltage standard in the UK in Europe is only 240V, while the voltage standard in other countries is between 120 and 220V, which is very easy to burn out the internal structure of the LED display. Therefore, to protect the electronic components inside the LED, it is necessary to install a lightning arrester. 2. LED display installation waterproof device LED displays installed outdoors are greatly affected by the environment, so they must have solid environmental resistance. The most taboo thing for electronic equipment is to get wet with water. Water is fluid and very conductive, and it is easy to burn out the circuit when disturbed by water. In addition, the damage caused by water to electronic products is easy to rust. Once the electronic products are rusted, the circuit will lose its electrical conductivity. Therefore, after the first storm, please check whether the screen is leaking. If there is, please use a hair dryer to dry it. It is important to keep the LED display dry and prevent water from flowing into the electronic equipment in the box. (If there is a water leakage problem, for the sake of safety, you must find a professional to find out the cause) 3. Selection of circuit chips The circuit chip chooses to resist the temperature of the external environment. If the extreme temperature climate is encountered, a good industrial-grade circuit chip can operate normally even if the operating temperature is between minus 40 degrees Celsius and 80 degrees Celsius. We often see the fire or crash of the LED display screen in a high-temperature environment or the start of the LED display screen in a low-temperature environment; this is because the circuit chip of good quality is not selected. Of course, there are other reasons, such as very few in the later stage, maintenance, prolonged use, etc. Therefore, it is very important to have a circuit chip that can adjust according to the outdoor ambient temperature. 4. Install cooling equipment Even if there is a good circuit chip, why does the outdoor LED display box need cooling equipment? The main reason is that the screen will generate a certain amount of heat when it is powered on and working. If the heat cannot be discharged and accumulated to a certain extent, the internal temperature will become higher and higher, which can cause serious burns and make the display screen unable to run the job. Therefore, do a good job of internal ventilation and heat dissipation measures of the LED screen to keep the internal temperature between 10 degrees and 40 degrees, which is beneficial to the life of the outdoor LED display. Although there are many cooling systems in the outdoor LED display, due to the changeable and extreme environment, in countries with high temperatures and high heat, air conditioners are generally installed inside to cool down, which is safer and more stable. 5. Choose ultra luminous light emitting diodes The biggest reason for choosing ultra-high luminosity light-emitting lamp beads is the display effect, which will not affect the displayed advertising content because of the high-brightness sunlight outside. The internal photosensitive chip adjusts the brightness according to the environment. When the brightness of the outdoor LED display is not enough, in a hot and bright environment, the displayed content will have problems such as light color and blur. The choice of waterproofing, cooling system, and brightness need to be explained here. When purchasing, you need to explain these data to the merchant or manufacturer of the display screen. For example, IP65 is required for waterproofing; several fans are installed in the cooling system, etc. What type of lamp is it? Beads all need to be figured out.

15｜12｜2023

How to Set the Parameters of LED Display Control Card?

When setting the software parameters of the led display control card, you often encounter some problems. For example, don't know how to set the parameters, what the password is, can’t find the software, etc. Different manufacturers of control cards have different parameter items. Meiyad has classified it into three categories: basic parameters, auxiliary parameters and core parameters. Outdoor led display control software has three parameters:Firstly, basic parameters If the the basic parameters settings are incorrect, communication or display will not be possible or the display will be abnormal. The basic parameters include 10 items including display width and height, control card address, baud rate, IP address, port number, MAC address, subnet mask, gateway, refresh frequency and shift clock frequency. Second, auxiliary parameters Auxiliary parameters are parameters set for better display and control, including control card name, communication display mark, brightness and screen switching time. Third, core parameters The core parameters are necessary parameters for the outdoor led display. If the settings are incorrect, the display may not be displayed at all, or the screen may be burned out. The core parameters include cascade direction, OE polarity, data polarity, display type, color, scanning method, point order and row order, a total of 8 items. LED display control software parameter configuration method: For the configuration of basic parameters and auxiliary parameters, input boxes and selection boxes are provided. After the user inputs and selects, they can connect to the display screen and set directly. As for the core parameters, it can be completed using three methods: professional quick check, intelligent configuration and external file configuration. 1. Professional quick check For common and commonly used models of led screens, the parameters are generally fixed. In this case, they can be organized into files or tables in advance, and the configuration can be loaded during debugging. 2. Intelligent configuration For uncommon or uncertain led displays whose parameters are unknown, intelligent configuration can be used to determine their configuration parameters and then be saved for later use. 3. External file configuration Import smart configuration or other external files built into the configuration. Among the three configuration methods of core parameters, intelligent configuration is a more important configuration method. Its main processes and functions are as follows: 1. Start smart configuration. 2. Through the wizard, the user and the led display can make human-computer interaction selections and start the intelligent configuration operation by filling in the initial parameters, determining the OE polarity/data polarity, determining the color, determining the scanning method, determining the point sequence, and determining the row. sequence and generate configuration parameters to complete the determination of core parameters. 3. Return to intelligent configuration parameters. 4. Connect the display and set parameters. 5. If correct, perform output parameter operation. 6. Select the external file and save it for later downloading. At this point, the intelligent configuration of the display screen is completed. Summary: The outdoor led display needs to be correctly configured with more than 20 parameters before it can be lit. You can imagine how cumbersome and complex it is. If the settings are incorrect, the display may not be displayed at all, or the display screen may be burned, causing significant economic losses and delays in construction. Therefore, it is understandable that some led display control software is complex in design and inconvenient to use for the sake of caution and stability.

13｜07｜2024

The Difference Between SMD, DIP, COB And GOB LED Screen

The terms SMD, DIP, COB, and GOB refer to different technologies used in LED screens, each with its own characteristics and applications: SMD (Surface Mount Device) LED Screen: SMD LEDs are the most commonly used in modern LED screens. They consist of three LED chips (red, green, and blue) packaged together as a single pixel. SMD LEDs are smaller in size, allowing for higher pixel density and thus higher resolution screens. They generally offer better color accuracy, wider viewing angles, and are more energy-efficient compared to older technologies like DIP. DIP (Dual In-line Package) LED Screen: DIP LEDs are older technology where each pixel is made up of three individual LED bulbs (red, green, and blue). They are larger in size compared to SMD LEDs, which limits the pixel density and resolution. DIP screens are more robust and can emit brighter light, making them suitable for outdoor displays where high brightness is required. They have narrower viewing angles and consume more power compared to SMD LEDs. COB (Chip-on-Board) LED Screen: COB technology involves mounting multiple LED chips directly onto a substrate to form a single module. It eliminates the individual LED packaging found in SMD and DIP, resulting in a higher packing density and improved thermal management. COB LEDs are often used in high-power applications where brightness and efficiency are critical. GOB (Glass-on-Board) LED Screen: GOB technology encapsulates the LED module in a transparent epoxy resin or similar material on a PCB (Printed Circuit Board). This encapsulation enhances the durability and protects the LEDs from environmental factors. GOB screens are typically used in outdoor and rugged environments where protection against moisture, dust, and physical impact is necessary. Key Differences:Size and Pixel Density: SMD LEDs are smaller and allow for higher pixel density compared to DIP LEDs.Color Accuracy and Viewing Angles: SMD LEDs generally offer better color accuracy and wider viewing angles than DIP LEDs.Brightness and Power Efficiency: DIP LEDs can be brighter but consume more power compared to SMD LEDs.Application: SMD LEDs are more commonly used indoors and for high-resolution screens, while DIP LEDs are favored for outdoor and large-scale displays where brightness is crucial. COB and GOB technologies cater to specific needs for durability and specialized applications. Choosing between these technologies depends on factors like the intended use (indoor vs. outdoor), desired resolution, viewing angles, and environmental conditions where the LED screen will be used.

15｜03｜2025

In-Depth Analysis of GOB LED Display: Technology, Advantages, and Applications

In recent years, the development of display technologies has evolved rapidly, with new advancements in display panels providing higher performance, better durability, and enhanced user experiences. One of the most notable innovations in this area is the GOB (Glue On Board) technology, a key process used in modern display production. But what exactly is GOB, and why is it gaining so much attention in the industry? Let’s dive into the details. What is GOB?GOB, which stands for Glue On Board, is a manufacturing process primarily used in the production of display panels, particularly for OLED and LED screens. The GOB process involves applying a layer of protective resin or glue over the LED chips to secure them onto the display panel, providing physical protection while enhancing the performance and durability of the screen. This process is particularly beneficial in the mass production of large, high-resolution displays, where durability and reliability are critical. The GOB technology helps solve many issues associated with traditional display manufacturing methods, including risks of water and dust penetration, as well as challenges in chip alignment and fixation. What Industry Pain Points Does GOB Solve?1. Waterproofing and Dustproofing One of the biggest challenges in display technology, particularly in outdoor and mobile applications, is ensuring the screen is protected from environmental elements like water and dust. GOB offers a strong, protective layer that significantly reduces the risk of water and dust infiltrating the LED chips, which can lead to display failure or reduced performance over time. 2. Chip Protection In traditional methods, LED chips are more exposed, which can make them vulnerable to physical damage during the manufacturing process or later in the product’s lifespan. GOB encapsulates the chips, providing an extra layer of protection against mechanical stress, temperature variations, and external impacts. 3. Improved Longevity and Reliability By enhancing the durability of the individual components and protecting them from environmental damage, GOB extends the overall lifespan of display screens. This is especially crucial for devices that are constantly exposed to heavy usage or extreme conditions, such as automotive displays, outdoor LED signage, and large-scale digital LED billboards. 4. Improved Uniformity GOB technology also helps to maintain the uniformity of the display, improving the overall quality of the visual experience. By securing the LEDs more precisely and reducing misalignments, GOB helps achieve better consistency in brightness and color distribution across the screen. Advantages of GOB Technology1. Enhanced Durability The glue or resin used in the GOB process strengthens the display panel by providing an additional layer of protection for the LEDs. This results in a more durable and robust display, capable of withstanding harsher environments, such as outdoor settings or vehicles, where screens are exposed to significant vibrations and weather conditions. 2. Improved Visual Quality GOB technology leads to more stable and consistent light emission from the LEDs. The resin coating enhances light transmission and minimizes light leakage, ensuring that the display offers superior image clarity and brightness. 3. Cost-Effective Manufacturing Compared to traditional bonding methods that require precision placement of LED chips, GOB allows for a simpler and more efficient production process. This can reduce manufacturing costs and improve the scalability of production for large volumes of displays. 4. Water and Dust Resistance The resin layer provides an extra defense against moisture, dust, and dirt, which can otherwise infiltrate the screen and affect performance. This makes GOB particularly suitable for displays that need to function in outdoor or industrial environments where exposure to such elements is common. GOB Process: A Step-by-Step Breakdown The GOB process consists of several key steps that are crucial for the successful application of this technology: 1. Preparation of the Display Panel The base of the display panel, typically a glass substrate, is prepared by ensuring it is free from contaminants and properly cleaned. 2. Placement of LED Chips The LED chips are carefully placed onto the panel. They are aligned using automated equipment, ensuring that each chip is accurately positioned for optimal display performance. 3. Application of the Glue or Resin Once the LEDs are positioned, a special glue or resin is applied over the chips. This material acts as a protective layer that secures the chips and provides insulation against external elements. 4. Curing Process The glue is then cured using heat or UV light to harden it, ensuring the chips are firmly attached and well-protected. 5. Final Testing and Quality Control After curing, the panel undergoes rigorous testing to check for any defects in alignment, brightness, or color uniformity. Only those panels that meet the strict quality standards are approved for use. What Type of Display Panels is GOB Suitable For? GOB technology is particularly well-suited for display panels that require high durability, such as: 1. OLED Displays OLED panels, which are often used in smartphones, televisions, and other high-end devices, benefit greatly from GOB due to the protection it offers against moisture and other environmental factors that could degrade the OLED’s performance. 2. Outdoor and Automotive Displays GOB is ideal for outdoor LED signage, digital LED billboards, and automotive displays that must withstand challenging conditions, such as direct sunlight, rain, and dust. 3. Large-Scale LED Screens For large-format LED displays in stadiums, shopping malls, or transportation hubs, GOB ensures that the LEDs remain in place and protected over time, maintaining the integrity of the display even in high-traffic environments. 4. Flexible and Wearable Displays GOB can also be applied to flexible LED screen and wearable displays, where the additional protection and durability are key in ensuring long-term performance in various use cases. Conclusion GOB technology represents a significant advancement in display manufacturing, addressing key pain points such as environmental protection, durability, and cost efficiency. By providing an additional layer of protection for LED chips, GOB ensures that displays remain functional and visually consistent over time, even under challenging conditions. This makes it an ideal solution for a wide range of industries, from consumer electronics to outdoor advertising. As demand for high-quality, durable displays continues to grow, the adoption of GOB technology is expected to expand, solidifying its place as a critical innovation in the world of display technology.

15｜04｜2025

10 Tips to Consider When Buying LED Church Screens

When integrating LED displays into church settings, several design considerations are essential for ensuring both functionality and aesthetics: 1. Screen Size and Placement Determine the appropriate screen size based on the sanctuary's size and seating arrangement. Larger screens or multiple smaller screens may be needed for bigger spaces. Placement should ensure that all attendees, regardless of their seat location, have a clear view without obstruction. 2. Resolution and Pixel Pitch Select a resolution and pixel pitch that match the viewing distance. For large auditoriums, a lower pixel pitch (higher resolution) is crucial for maintaining image clarity from a distance. Ensure the display is clear enough for text and graphics to be readable. 3. Ambient Light Conditions Consider the ambient lighting conditions in the sanctuary. LED displays perform well under various lighting conditions, but choosing a screen with high brightness can prevent glare and ensure visibility in brightly lit spaces. 4. Integration with Existing Systems Ensure the LED display integrates seamlessly with existing AV and lighting systems. Compatibility with audio systems, video sources, and control interfaces will facilitate smooth operation and content management. 5. Aesthetic Integration Design the display to complement the church's architectural and interior design. The display should enhance the worship environment without dominating or clashing with the overall aesthetic. Consider frame styles, mount types, and color schemes that blend with the church’s decor. 6. Accessibility Position screens at heights and angles that are accessible to everyone, including those with disabilities. Ensure text size and contrast are adjusted for readability by all members of the congregation. 7. Content Management Implement a user-friendly content management system to facilitate easy updates and scheduling. This system should allow for real-time changes to announcements, lyrics, and other content during services. 8. Durability and Maintenance Choose robust, high-quality LED displays designed for long-term use. Consider maintenance access and support options to address any issues promptly without disrupting services. 9. Power and Cooling Plan for adequate power supply and cooling requirements. LED displays can be power-intensive and may require proper ventilation to avoid overheating. 10. Budget Considerations Balance the desired features with the budget constraints. While high-end displays offer advanced features, there are also cost-effective options that provide excellent performance for church environments. By carefully considering these design factors, churches can effectively integrate LED displays into their worship spaces, enhancing both the functionality and visual appeal of their services.

11｜05｜2025

Step-by-Step Guide: How to Repair an LED Display Module?

LED display modules are widely used in various applications, from outdoor LED billboards to indoor LED screens. However, like any electronic device, they are prone to wear and tear over time. Fortunately, many common issues, such as broken LED beads or malfunctioning rows of lights, can be repaired with the right tools and techniques. In this blog, we’ll walk you through two typical repair scenarios for LED display modules and guide you on the necessary steps to get them functioning again. 1. Repairing a Broken LED Bead on the Module One of the most common issues with LED display modules is when an individual LED bead becomes damaged, often due to physical impact or mishandling. A broken LED bead can lead to sections of the screen failing to light up properly. Here's a step-by-step guide to fixing a broken LED bead: Step 1: Cut the Solder Pad Paper Start by cutting a piece of solder pad paper that’s appropriate for the size of the broken LED gap. This will act as the base for fixing the new LED bead. Step 2: Place the Solder Pad Paper Position the solder pad paper over the gap left by the broken LED bead. Ensure that it aligns properly with the surrounding pads. Step 3: Heat and Fix the Solder Pad Paper Use a heat gun or a soldering iron to heat the solder pad paper. This will help it adhere to the module's base. Step 4: Add Solder to the Solder Joint Once the solder pad paper is fixed in place, add solder to the joints where the LED bead will be attached. Step 5: Apply Solder Paste to the LED Bead Pins Before placing the new LED bead, apply a small amount of solder paste to the pins of the LED. This will help the bead adhere properly when heated. Step 6: Place and Align the New LED Bead Carefully align and place the new LED bead in the gap where the old one was. Ensure it is perfectly in place for proper functioning. Step 7: Heat and Fix the LED Bead Now, direct the air gun or heat gun at the LED bead. Heat it until the solder paste melts, fixing the LED bead securely in position. Step 8: Final Check After the bead is in place and has cooled down, check the repair by testing the module. Ensure the new LED bead is functioning properly before reinstalling the module. Click on the link to view our repair video: https://www.youtube.com/shorts/2HRIOX7XGOE2. Repairing a Row of Uncontrolled Lights on the LED Display Sometimes, an entire row of LED beads on the module might remain constantly lit, regardless of the signal sent to the display. This could be due to a short-circuited LED bead or another component failure. Here's how to fix this issue: Step 1: Identify the Problem Module First, locate the module with the row of lights that are stuck on. If only one row is malfunctioning, the issue is likely isolated to that particular module. Step 2: Remove the Faulty Module Carefully remove the faulty module from the display. You may need to unscrew or unclip it, depending on the specific setup. Step 3: Locate the Short-Circuited LED Bead Inspect the row of LED beads to identify which one is short-circuited. You can do this by visually inspecting the beads or using a multimeter to check for continuity between the pins of the LEDs. Step 4: Use the Heat Gun to Inspect Each LED Use a heat gun to heat each LED bead in the affected row one at a time. As you heat the individual LEDs, you may notice one that stops functioning or begins to flicker, indicating the short-circuited bead. Step 5: Remove the Faulty LED Bead Once you have identified the faulty LED, carefully remove it using tweezers or a soldering iron to desolder it from the module. Step 6: Replace with a New LED Bead After removing the damaged LED bead, replace it with a new one of the same type and specifications. Step 7: Heat and Fix the New LED Bead Apply solder paste to the new LED's pins and use the heat gun or soldering iron to fix it in place. Ensure the new LED bead is securely attached to the module. Step 8: Test the Module After replacing the faulty LED, test the module again to make sure the row of lights is now functioning properly. If the issue is resolved, you can reinstall the module back into the display system. Click on the link to view our repair video: https://youtube.com/shorts/ooo34pnG11E?si=ZM4KS_lNsTexBqh2Conclusion Repairing an LED display module may seem daunting at first, but with the right tools and approach, it is certainly manageable. Whether you're fixing a single broken LED bead or dealing with a row of malfunctioning lights, the steps outlined above should guide you in making an effective repair. Always remember to handle components carefully to avoid further damage, and test the module thoroughly after repairs to ensure everything is working as expected. By learning to troubleshoot and repair common issues with LED display modules, you can extend the lifespan of your equipment and keep your display performing at its best.
